[01]Forged fittings

Socket weld pipe fittings

1/2" – 4" NB

High-pressure forged fittings — elbows, tees, couplings, caps, crosses, olets and unions — for compact, leak-tight small-bore piping. Available from 1/2" to 4" NB in 3000#, 6000# and 9000# class across every material grade.

Request a quoteView specifications
Paras is an EIL-approved manufacturerApproved by Engineers India Limited (EIL)
FIG. 00 — FORGED SOCKET WELD FITTINGS · ASME B16.11NTS
Forged stainless socket weld elbows, tees, couplings, unions and caps
Dwg no.
PEW—SW
Material
CS · SS · DSS · AS
Sheet
02 / 04
[02]Product range

The complete socket weld range

Manufactured in-house across every size, schedule, rating and material grade.

09fitting types
PEW—SW—01 → 09

Swipe · tap to inspect01 / 09

PEW—SW—01Elevation · NTS
FIG. 02.1

Elbow

Forged elbow for a tight change of direction in small-bore lines — 45° and 90°.

Forms45°90°
Size range
1/2" NB – 4" NB
Pressure class
3000#·6000#·9000#
Type
Socket Weld Ends
Materials
CS·SS·DSS·AS
Standards
ASME/ANSI B16.11+2
Request a quote
[03]Technical specifications

Rated 3000# to 9000#

Forged socket weld fittings from 1/2" to 4" NB, in carbon, stainless, duplex and alloy steel — manufactured and inspected to ASME/ANSI B16.11, MSS SP-97 and MSS SP-83.

Families
04
Standards
03
Size · NB
1/2"–4"
03.1

Quick specs

PEW—SW
Size range

1/2"–4"

NB · nominal bore

Manufactured range1/2" NB – 4" NB
Pressure class

3000# – 9000#

  1. 3000#
  2. 6000#
  3. 9000#
Materials

ASTMA105·A350·A182

  • CS
  • SS
  • DSS
  • AS
Type

Socket Weld Ends

Standards

ASME/ANSI B16.11

MSS SP-97·MSS SP-83

All 03 standards
03.2

Material grades

Select a family

Forged in carbon, stainless, duplex and alloy steel to ASTM A105, A350 and A182.

PEW—SWM—01
CS
Carbon steel
ASTM A105 · A350
ASTM A105
A105 / A105N
ASTM A350
LF2 (LTCS)
03.3

Pressure class

Pressure rating (Class#)
Class3000# – 9000#
  1. 3000#
  2. 6000#
  3. 9000#

Bar length to scale

03.4

End connection

Socket Weld Ends
FIG. 03.4 — Socket detail

Type

Socket Weld Ends

The pipe end seats inside a machined socket and is fillet-welded around the outside — a compact, leak-tight joint for small-bore, high-pressure lines.

03.5

Standards

Dimension standards

Manufactured & inspected to

PEW—SW · 03 standards

  1. S-01ASME/ANSI B16.11
  2. S-02MSS SP-97
  3. S-03MSS SP-83
[04]Other product lines

Complete the line

Every Paras product line is manufactured in-house to international codes — source fittings and flanges together on a single enquiry.

  1. 01BW
  2. 02SW
  3. 03TH
  4. 04FL

You are on sheet 02 · SW

PEW—THNext sheetSheet 03 / 04

Threaded fittings

Screw Weld Pipe Fittings

Threaded elbows, tees, couplings, caps & olets — NPT / BSP / BSPT.

Size
1/2" – 4" NB
Threads
NPT · BSP · BSPT
Class
3000# · 6000# · 9000#
Open sheet 03
PEW—FL

Flanges

Weldneck, slip-on, blind, threaded & socket-weld — 150# to 2500#.

View datasheet
PEW—BW

Butt Weld Pipe Fittings

Elbows, tees, reducers, caps, stub ends & crosses — 1/2" to 64" NB.

View datasheet
