[01]Threaded fittings

Screw weld pipe fittings

Threaded forged fittings — elbows, tees, couplings, caps, crosses, olets, unions and nipples — for fast, weld-free small-bore connections. Available from 1/2" to 4" NB in NPT, BSP and BSPT across every material grade.

Request a quoteView specifications
Paras is an EIL-approved manufacturerApproved by Engineers India Limited (EIL)
FIG. 00 — THREADED FORGED FITTINGS · NPT / BSP / BSPTNTS
Forged threaded tees, elbows, unions, couplings and caps
Dwg no.
PEW—TH
Sheet
03 / 04
[02]Product range

The complete screw weld range

Manufactured in-house across every size, schedule, rating and material grade.

10fitting types
PEW—TH—01 → 10

Swipe · tap to inspect01 / 10

PEW—TH—01Elevation · NTS
FIG. 02.1

Elbow

Threaded forged elbow for a tight change of direction — 45° and 90°.

Forms45°90°
Size range
1/2" NB – 4" NB
Pressure class
3000#·6000#·9000#
Type
Threaded/Screwed — NPT·BSP·BSPT
Materials
CS·SS·DSS·AS
Standards
ASME/ANSI B16.11+4
Request a quote
[03]Technical specifications

Cut to NPT, BSP and BSPT

Forged threaded fittings from 1/2" to 4" NB, rated 3000#, 6000# and 9000# — manufactured and inspected to ASME/ANSI B16.11, MSS SP-97 and MSS SP-83.

Families
04
Standards
05
Size · NB
1/2"–4"
03.1

Quick specs

PEW—TH
Size range

1/2"–4"

NB · nominal bore

Manufactured range1/2" NB – 4" NB
Pressure class

3000# – 9000#

  1. 3000#
  2. 6000#
  3. 9000#
Materials

ASTMA105·A350·A182

  • CS
  • SS
  • DSS
  • AS
Type

Threaded/Screwed Ends

NPTBSPBSPT
Standards

ASME/ANSI B16.11

MSS SP-97·MSS SP-83·B36.10·+1

All 05 standards
03.2

Material grades

Select a family

Forged in carbon, stainless, duplex and alloy steel to ASTM A105, A350 and A182.

PEW—THM—01
CS
Carbon steel
ASTM A105 · A350
ASTM A105
A105 / A105N
ASTM A350
LF2 (LTCS)
03.3

Pressure class

Pressure rating (Class#)
Class3000# – 9000#
  1. 3000#
  2. 6000#
  3. 9000#

Bar length to scale

03.4

End connection

NPT·BSP·BSPT
FIG. 03.4 — Thread detail

Type

Threaded/Screwed Ends

Screws straight onto threaded pipe — fast, weld-free assembly for small-bore lines, in three thread forms.

T-01

NPT

T-02

BSP

T-03

BSPT

03.5

Standards

Dimension standards

Manufactured & inspected to

PEW—TH · 05 standards

  1. S-01ASME/ANSI B16.11
  2. S-02MSS SP-97
  3. S-03MSS SP-83
  4. S-04B36.10
  5. S-05B36.19
[04]Other product lines

Complete the line

Every Paras product line is manufactured in-house to international codes — source fittings and flanges together on a single enquiry.

  1. 01BW
  2. 02SW
  3. 03TH
  4. 04FL

You are on sheet 03 · TH

PEW—FLNext sheetSheet 04 / 04

Flanges

Flanges

Weldneck, slip-on, blind, threaded & socket-weld — 150# to 2500#.

Size
Forged to 48" · plate to 100" NB
Rating
150# – 2500# · PN6 – PN64
Standard
ASME B16.5 · B16.47 · MSS SP-44
Open sheet 04
PEW—BW

Butt Weld Pipe Fittings

Elbows, tees, reducers, caps, stub ends & crosses — 1/2" to 64" NB.

View datasheet
PEW—SW

Socket Weld Pipe Fittings

Elbows, tees, couplings, caps, crosses, olets & unions — 3000#–9000#.

View datasheet
